M660

Self-Contained Marine Lanterns

The M660 is a high-performance, long life, easy-to-use and cost effective self-contained solar LED marine lantern. The M660 features a Li-ion battery pack that extends the service life of the lantern up to eight years. M660 has four different mounting options and can be programmed and controlled with Bluetooth® Control.

To view performance in your installation location, visit Marine Selector Tool at www.carmanahmarine.com/selector.



Technical Data
MAIN TECHNICAL SPECIFICATION
Lens visual/Mechanical diameter177 mm
Lens materialUV stabilized Polycarbonate
Light sourceHigh Power Light Emitting Diode (LED)
Vertical divergence>8° (FWHM)
Solar moduleHigh efficiency cells; MPPT
BatteryLi-ion (IEC 61233)
Degree of ingress protectionIP 68
Weight0.8 kg
Overall height (excl. bird deterrents)105 mm
Installation (adapter)3 x M6 on 150mm and 3 x M12 on 200mm
Installation (pole mount)3 x #10-14 60mm or 73mm diameter
